Frigstad D90 semi-submersible drilling unit - ,

The Frigstad D90 is a semi-submersible drilling unit design for ultra deepwater exploration & development. Peutz has conducted wind tunnel tests to determine the wind and current loads for stability assessment and DP. In addition a full test matrix of helicopter deck turbulence measurements has been conducted according to the CAP 437 requirements. The tests have been conducted at the wind tunnel facility of Peutz.

Wind Load JIP FPSO - ,

The Wind Load JIP aimes at setting new standards for wind tunnel measurements of wind loads and CFD calculations for the maritime and offshore industry. Peutz has conducted wind tunnel measurements of wind loads on a model of a FPSO and a semi-submersible production unit. The effects of changes in roughness of the boundary layer, variation of configurations as well as sensitivity to different types of set-up have been investigated.

Wei-Wu-Ying Center for the Arts - Koahsiung, Taiwan

The new National Performing Arts Centre is a 141.000 m2 theatre complex built in the Wei-Wu-Ying Metropolitan Park in Kaohsiung, Taiwan. The design includes a concert hall with 2000 seats; an opera house with 2250 seats; a playhouse with 1250 seats; a recital hall of 500 seats and 1000 m2 rehearsal rooms. Additionally an open-air stage is to be built on the roof.

Helicopter deck hot gas plume and air quality: AEGIR - ,

To ensure safe helicopter operations offshore helicopter deck certifiction (CAP 437, NORSOK C-004) requires an assessment of temperature rise due to hot exhaust gas plumes in the airspace above the helideck. The plume trajectory can be visualised in a smoke visualisation test in the wind tunnel. The temperature rise can be directly measured in a buoyant plume tracer gas experiment on a scale model in the wind tunnel.

Wind tunnel model: Forum Trabzon - Trabzon, Turkey

The famous Sumela Monastery, numerous sites of historic interest and its unspoiled beauty make Trabzon one of the most interesting tourist destinations in Turkey. With wind tunnel testing we assessed the possible wind climates inside the shopping centre, at the entrances, on the rooftop terraces (restaurants) and in the car park.

Forum Bornova - Izmir, Turkey

Forum Bornova was the first shopping and lifestyle centre developed by Multi Turkmall in Turkey. It consists of two boulevards, two squares and four streets. There are wooden canopies, small ponds, bridges, a tower, a lot of mosaic, wooden pergolas, palm trees, fountains, roof gardens with restaurants and bars. Wind speeds at the site of the shopping centre are high by Turkish standards.

World Port Center - Rotterdam, The Netherlands

Standing alongside the distinctive Hotel New York on Rotterdam’s Wilhelmina Pier is the World Port Center. The office building’s principal occupant is the Port of Rotterdam Authority. The top floors of the 32-storey building are devoted to large conference rooms that provide a fantastic view over the port.
In consultation with the client and the architect, steps were taken to find solutions for the problems with the wind climate around the building, and particularly on the terrace.

Concertgebouw Amsterdam - Amsterdam, The Netherlands

The Grote Zaal (Main Hall) of the Concertgebouw went through major renovations between 1985 and 2002, in respect of which eventually all wall and ceiling surfaces as well as the chairs and stage were renewed. The Kleine Zaal (Recital Hall) underwent complete refurbishment in 2004. As in the Grote Zaal, the acoustic quality was preserved by taking every last detail into account.

Baiyun International Congress Centre - Guangzhou, China

The province of Guangdong and the municipalities of Guangzhou wished to built a new, prestigious congress centre for international and national conferences, extensive meetings of the provincial and municipal governments and for commercial fairs and cultural manifestations. The congress centre has a volume of 22,000 m³.

Wind and current loads for DP: SapuraKencana 3500 - ,

Measurements of the wind loads have been conducted on a scale model of the Ulstein designed SapuraKencana 3500 vessel. The wind loads are measured with a high frequency 6-component balance system, while the model is exposed to an approach flow according to the actual maritime wind velocity and turbulence boundary layer profile. Also current loads for several stinger configurations have been measured in the wind tunnel.

Wind loads for DP and stability: Drillship - ,

Measurements of the wind loads have been conducted on a scale model of an Ulstein designed drillship. Through wind tunnel measurements of the wind load coefficients the highest accuracy is achieved in calculation of required thrust capacities, DP capability and DP definition and optimisation.

Wind loads for DP and stability, helideck safety: Arctic drillship - ,

Ships designed for extreme conditions such as the arctic can show aerodynamic properties which are significantly different from conventional ship shapes. Measurements of the wind loads on the arctic drillship have been conducted in the Peutz wind tunnel. Measurements of turbulence and hot exhaust gas dispersion are conducted for CAP 437 certification of both helicopter decks.
